DXZ160-R

IP-rated, rugged client for reliable connection from any environment.

Introducing the DXZ160-R Quad Display Rugged Trusted Zero Client, the ultimate solution for demanding environments where reliability and performance are paramount.

Engineered to withstand harsh conditions with its IP5X dust protection and rugged all-metal construction, the DXZ160-R delivers exceptional visual experiences with support for up to four 4K displays at 60 frames per second.

Powered by the high-performance AMD V1605B embedded quad-core GPU with Vega 8 graphics, this zero client ensures smooth operation even with resource-intensive tasks. Its dual network interfaces, including wired Ethernet and SFP fiber, offer flexible deployment options to meet the needs of any enterprise.

Learn more about Trusted Zero Clients

Building on the proven deployment history of Amulet Hotkey DXZC and DXZ4 Zero Client into secure applications, Trusted Zero Client incorporates modern security practices whilst maintaining the same focused and simple user experience.

DXZ160-R easily fits into Zero Trust security architecture by using centrally managed users, multi-factor authentication, and centralised device management built around HP Anywhere Trust Centre. Using the Amulet Hotkey DMS tool for client management, ensuring all clients are up to date with firmware deployment, configuration, and security policies.

Each Amulet Hotkey Trusted Zero Client is granted a unique, immutable birth certificate at manufacture to uniquely identify with the Trust Center and enable continuous real-time authentication during use.

DXZ160-R Trusted Zero Client Specifications
Mounting Options	100mm VESA on optional mounting bracket
Cooling	Passive air cooled, fanless design with external heatsinks
Processor	AMD V1605B embedded quad core CPU with integrated Vega 8 GPU
Memory & Storage	8GB RAM DDR4 RAM 32GB solder-down eMMC storage for Trusted Zero Client Firmware
Duel Network Connections	Copper RJ45 10/100/1000 Mbit/s Optional SFP module supporting 1000Mbit/s LR and SR fibre and copper
Form Factor	Rugged client – vertical or horizontal orientation with rubber feet. Ingress protection 5x rated (protection against fine dust) when using port covers on unused IO connectors.
Operating Conditions	0°C (32°F) to 40 degC (104°F) ambient temperature
USB connections	Front – Four USB-A 3.0 Rear – Two USB-A 2.0
Security	Zero Trust is ready with Two-factor authentication options and continuous real-time device authentication. IEEE 802.1X network authentication. Cable lock slot
TPM 2.0 Compliant	TCG-certified discrete hardware TPM
Power	Universal 120W AC power with external PSU
Compliance	TAA Compliant EMC: EN55032 and EN55035 Safety: UL62368-1 and IEC62368-1 IL Listed
Power	Universal 120W AC power with external PSU
Dimensions	56mm (2.2in) wide, 178mm (7.0in) deep, 192mm (7.6in) high
